Horizontal cement silo is a new type of cement mixing silo, which is used in conjunction with concrete mixing plant. The internal pressure reducing structure of the cement bin can effectively prevent cement arching. At the same time, using special flow aids, the cement can be discharged at a constant rate, stored for a long time, not compacted, and the hidden dust collector can ensure that there is no dust on the material.

The horizontal cement warehouse has the characteristics of convenient loading and unloading transportation (not super wide, not super tall, not super long). It is not restricted by the height of the factory building, and can be placed indoors to avoid being too tall and dazzling outdoors. Horizontal cement silos are suitable for the storage of bulk cement in engineering construction, road and bridge water conservancy, urban construction and other projects. The utility model has the advantages of waterproof, moisture-proof, preventing cement loss, reducing urban air dust pollution, small floor area, long service life, low cost and the like.

Horizontal cement silo is a kind of equipment commonly used in construction, because cement is usually made in situ when in use, and cement tanks are often used with concrete mixing plant, so that the cement used in construction can be efficiently manufactured. In the horizontal cement tank partial structure, the bottom is supported on the entire structure by four round tube legs, and the partial is made by welding. At the same time, an arch breaking device is provided at the bottom of the equipment to ensure the smooth discharge of powder. The internal induction device can well grasp the use of materials in the cement tank.

The working principle of the horizontal cement tank: After the cement bin is fixed, it is transported by the bulk cement truck to the construction site, and then the transmission pipeline of the bulk cement truck is connected with the feed pipe of the cement bin (cement tank). The cement in the tank is transported to the cement silo (cement tank) by the air pressure of the bulk cement truck. During the process of transporting the cement to the silo, the operator kept pressing the button of the dust collector vibration motor to shake off the cement attached to the dust collector bag to prevent the bag from being blocked and the silo from bursting. Once the bag is clogged and the pressure in the warehouse exceeds the safety pressure of the pressure safety valve on the top of the warehouse, the pressure safety valve can be opened to release the pressure in the warehouse to prevent an explosion accident. Through the high and low material levels, it can be observed that the bin is full and lacking. When unloading is required, first open the cone-bottom manual unloading valve, and then transport the cement out through the cement conveyor (screw conveyor). During the unloading process, if the "arching" phenomenon occurs, the solenoid valve button of the arch breaking device should be pressed in time to purge the air to eliminate the "arching" phenomenon and feed to ensure the smooth supply of cement.
