Concrete Batching And Mixing Plant Manufacturers HZS-50
Model
HZS-25
HZS-35
HZS-50
HZS-75
Capacity
25m³/h
35m³/h
50m³/h
75m³/h
Get Fast Quote
Leave My Questions
HAVE QUESTIONS?PLEASE LEAVE YOUR MESSAGE
*
*
FEATURES
TECH SPEC
VIDEO

HZS50 Hopper Lift Type Concrete Batching Plant is widely used for building bridges, dams, ports and water conservancy facilities; It is also applicable for small and medium-sized manufacturing factories for concrete pre-cast elements. Hopper batching plant has wide application in industrial concrete mixing projects where temporary production requires ±2% error in concrete. It has characteristics of less land occupation, easy maintenance, easy installation and simple operation, so it is much more popular on the market, which is a smart investment. In China, we use cement. Additive, water, sand, pebble, etc as raw materials, through loading, conveying, storing, batching, weighing, mixing and unloading, can produce finished concrete that meets quality requirements.

1. Horizontal twin shaft compulsory mixer has the strong mixing ability with uniform mixing and big production output. The admixtures are widely mixed by the shafts.

2. The mixing shafts adopt anti-binding technology to prevent the cement from binding on the shafts.

3. Mixing paddles, arms and blades are made of special high chromium and high manganese alloy materials. The wear resistance of the mixing paddles saves time and cost to replace. at the same time,improves the machines durability and reliability.

4. The greasing system, which is controlled by central control system, lubricates the greasing points at the fixed position, fixed time and fixed quantity;

5. Decelerating system uses high-speed, synchronized, and closed planetary decelerators.

6. The opening of discharge gate can be adjusted by hydraulic system as per specific requirements.

Type spectrum Bucket type
HZS-25 HZS-35 HZS-50 HZS-75
Theoretical Productivity (m³/h) 25 35 50 75
Mixer Model (mixer discharging capacity) JS500 JS750 JS1000 JS1500
Motor Power (kW) 18.5 30 2×18.5 2×30
Cycle Period (s) 67 72 72 72
Nominal Capacity of Mixer (L) 800 1200 1600 2400
Max.aggregate Size (mm) Φ60 Φ60 Φ60 Φ80
Aggregate Silo Capacity (m³) 3×3 3×5 3×8 3×12
Category of Aggregate (Optional) 3 3 3 3
Powder Lot Bin Capacity (t) 1×50 1×50 1×100 2×100
Material Discharging Height (m) 3.8 4.1 4.1 4.1
Accuracy of Aggregate (kg) (300~1500±2% (300~1500±2% (600~3000±2% (1000~3000)±2%
Accuracy of Cement (kg) (100~300±1% (100~300±1% (250~900±1% (300~1800±1%
Accuracy of Water (kg) (60~150±1% (60~150±1% (80~300±1% (200~800±1%
Accuracy of Addtive (kg) / (8~20±1% (8~20±1% (15~80±1%
 Srandard Reference Weight (Ton) ≈15 ≈18 ≈23 ≈30
Installed Capacity (kW) ≈65 ≈75 ≈100 ≈140
