Self Loading Mobile Concrete Mixers SR-4000
Model
SR-2600
SR-1500
SR-3500
SR-4000
Capacity
2600L Discharge Capacity
1500L Discharge Capacity
3500L Discharge Capacity
4000L Discharge Capacity
Get Fast Quote
Leave My Questions
HAVE QUESTIONS?PLEASE LEAVE YOUR MESSAGE
*
*
FEATURES
TECH SPEC
VIDEO

Self-loading concrete mixer is equipped with a powerful engine and 4 wheel steering, the self loading concrete mixer is easy to operate and go everywhere needed. It’s the combination of concrete mixer truck and cement mixer, which can automatically feed, measure, mix and discharge concrete mixture.

& Mixing Station + Loader + Concrete Mixer Truck

& One Machine With Multiple Functions

& Compact Structure

& Fast Relocation

& High Efficiency

& Accurately Mixed

& Mixed Evenly

& Saving Labor

Advantages Of Self Loading Concrete Mixer Truck

1. Self loading concrete mixer truck can rotate 270 degrees;

2. Self load, meter, mix and discharge;

3. Compact structure and easy movement;

4. High working efficiency and less energy consumption;

5. Cost and time-saving;

6. One-stop service, full automatic feeding, weighing, stirring and discharging;

7. High stirring quality and short stirring time.

8. The main hydraulic components are imported!

9. At least 5 workloads are saved per day!

10. Save electricity 100 degrees everyday without a blender!

Production technology

1. Shot blasting machine

When the elements are moved in to the machine, thousands of the little steel balls will heat on the surface of elements. Then the surface will become uneven, and it will increase the adhesive force. So it will ensure good painting.

2. Robot welding

Advanced technology of welding robots, which ensures high working efficiency and high accuracy

3. Closed painting room

In order to assure good painting and environmental protection, here is closed painting room. The machine will be shinning even after long time use. Moreover, we can also meet the environmental standards, so that we can manufacturer and delivery the equipment for our customers on time.

4. Sufficient elements stored

Here are sufficient elements stored in our factory, which ensures short delivery time. Meanwhile, we have ability to accept big orders from our customers.

5. Strict quality inspection

Quality inspection department, and strict inspection guarantees that the unqualified equipment will be reworked and will not be delivered to our customers.

Reasons to Choose Sinoroader

Our product is the top-choice for the concrete transportation for rural construction, urban construction, tunnel, airport, seaport, high-speed rail, beam field, bridge construction projects and so on.

Self-loading concrete mixer is equipped with a powerful engine and 4 wheel steering, the self loading concrete mixer is easy to operate and go everywhere needed. It’s the combination of concrete mixer truck and cement mixer, which can automatically feed, measure, mix and discharge concrete mixture.

Self-loading concrete mixer just needs an operator. Its safe and fast to operate. Greatly improve work efficiency and save manpower, reduce the the costs.Simple to use and easy to maintain, the concrete mixer is suited to all types of job-sites from congested city centres to remote villages.



Equipment Model SR1500 SR2600 SR3500 SR4000
Drum geometrical capacity 2500L 3900L 5400L 6000L
Discharge Capacity 1500L 2600L 3500L 4000L
Engine Model Yunnei Yunnei Yuchai Yuchai
Rated Power 55kw 76kw 92kw 95kw
Transmission 4 wheels drive,2 steering 4 wheels drive,2 steering 4 wheels drive,2 steering 4 wheels drive,2 steering
Fuel tank 95L 105L 155L 175L
Total hydraulic system capacity 95 liters 105 liters 115 liters 175 liters
Oil tank 16 liters 16 liters 16 liters 16 liters
Reducer HJ80-43 HJ80-43 HJ80-43 KY07-5-J
Hydraulic Pump FC50/40 CBGQ 2050/2032 CBGQ 2040/2080 Interpump
Hydraulic Motor BM5-160 BM5-160 BM5-160 HAA2FM56/61W-VTD527
Water tank 380L 650L 850L 950L
Water supply Time relay Time relay Time relay Time relay
Overall dimensions(L*W*H) 6100*2300*2490 7400*2400*3200 7100*2350*3560 7400*2500*3400
Wheelbase (mm) 2600 2800 2900 2480
Curb Weight (kg) 4800 6500 7500 7500
Drive Form Torque converter Torque converter Torque converter Torque converter
Drum rotate / 270º 270º 270º
Drum mixing speed (r/min) 13 13 13-20 17
Chassis Max.Speed (kn/h) 30 30º 30 35
Maximum grade 30º 30 30º 45º
Maximum turning radius (mm) 5270 5300 5300 4800
Minimum ground clearance (mm) 280 380 380 330
