Introduction of Concrete Mixer Truck

Sinoroader concrete mixer truck mainly applies to short and long distance mixing transport of concrete mixture, effectively delay concrete coagulation, avoids concrete stratification and education, and ensures construction quality and speed.

Sinoroader series concrete mixer trucks are Sinoroader Group’s independently developed products on the basis of absorbing domestic and foreign advanced techniques. The product mainly applies to short and long distance mixing transport of concrete mixture, effectively delay concrete coagulation, avoids concrete stratification and education, and ensures construction quality and speed.

Sinoroader series concrete mixer trucks include many models such as 2m3, 4m3, 6m3, 8m3, 10m3, 12m3 and can choose any trailor-made-for-mixer-truck special chasis both at home and abroad as supporting part according to customers’ choices. The stirring vat driving system adopts America and Germany closed circuit hydraulic system pump, motor, and reducer technology, and supporting hydraulic parts such as oil tank, radiator, filter, hose connector all adopt imported parts in order to ensure hydraulic system with long using life.

Features and Advantages of Concrete Mixer Truck
1.Special purpose chassis is specially developed for rural market, even narrow country road can be easily handled.
2.Optimized design of concrete mixing tank, improve loading ability, mixing on average without separation.
3.Mixing blade adopt three-dimensional double helix mixing design, reducing remnant rate to 0.6%,better than international standard 2%, leading the industry standard 0.7%-1%
4.The blade has unique wear-resisting protection structure, improving blade service life 80%

Service and Support

Sinoroader Group is a leading company in the concrete machinery industry with a vast product range of concrete batching plants, concrete mixers, concrete mixer trucks, concrete pumps, conveyor systems, cement silos and other various concrete machinery.
Sinoroader products were successfully used in most countries around the world, and were trusted by every customer.

Sinoroader Group has the special customer service department with over 30 service staffs, we establish every detailed customer files, and have skillful service engineers to solve customers’ problems and supply original spare parts at 7×24 hours every week. Any problems, please email us or call us.
We insist “customer-focused”, we supply the high quality and efficient service at pre-sales, sales and after-sales.

Gross weight(kg) 25000
Kerb weight( kg) 13010
Engine WD615.97E, 300HP , Euro II emission standard
Engine displacement (L) 9.726
Cab long cab with one sleeper, with two seats
Transmission HW15710, SINO 10 front and 2 reverse gear box
Steering ZF8098, German hydraulic steering with power assistance
Number of axle 3
Driving axle HC16,
casting axle, rated payload of each axle 16tons,strength wheel side reducer
Axle-loading(kg) 7000/18000(two axle paralleled)
Front/Rear track(mm) 1830/1830
front/rear Overhang (mm) 1550/2390
Wheel base (mm) 3825+1350
Number of spring leaf 9/12
Tires 11.00R20, Radial tire, 10pes,with one spare tire
Approach/departure angle 20/20
Maximum speed(km/h) 90
Tank Volume(m3) 8,9,10,12,15
Overall sizes (mm) 9115*2496*3850
