HZS180 concrete batching plant is mainly composed 0f PLD4800 batching machine, JS3000 concrete mixer, cement silos, automatic computer control system, electronic weighing, screw conveyor and others.It can mix fluidity concrete, plastic concrete, hard concrete and other proportioning concrete.The Fixed Concrete Batching Plant can be used for industry, construction, road, railway, bridge, water conservation, ports, and so on.
1. Adopts module structure,it is so easy to load/unload goods when shipment,also install more quickly.
2. Choosing spiral mixing system is to ensure high efficiency for concrete mixer,it can also extend mixer's working life by adopting high-rigidity and wearable case alloy steel mixing blades.
3. Aggregate lifting appliance adopts frequency control, thus providing smooth and reliable operation.
4. Aggregate batching machine adopts electric weighing system with sensor,its aggregate weighing accuracy is less than 2%,flexible combination of hoppers can be easy for your reasonable choice.
5. Automatic PC+PLC control system can ensure the flexible control and strong reliability
6. Human-machine intelligent control interface can complete intelligent operation and control smoothly.
7. Based on accurate weighing,it can produce high-quality concrete and meet the clients' requests.
8. Compact structure,strong shaft-end sealing and high efficiency for production capacity,flexible and easy to install and operate.
| Model | HZS90 | HZS120 | HZS180 | |
| Theoretical capacity(m³/h) | 90 | 120 | 180 | |
| Mixer | Model | JS1500 | JS2000 | JS3000 |
| Power(KW) | 2×30 | 2×37 / 4×37 | 2×55 / 4×55 | |
| Discharge capacity(m³) | 1.5 | 2 | 3 | |
| Max.aggregate size(gravel/pebble)(mm) | ≤60/80 | ≤60/80 | ≤60/80 | |
| Aggregate bins | Volumes | 12 | 20 / 2×20 | 20 / 2×20 |
| Belt conveyor capacity(t/h) | 450 | 600 | 800 | |
| Weighing scope | Aggregate(kg) | 3000±2% | 4×(2000±2%) | 4×(3000±2%) |
| Cement(kg) | 800±1% | 1000±1% | 1500±1% | |
| Coal ash(kg) | 200±1% | 400±1% | 600±1% | |
| Water(kg) | 300±1% | 400±1% | 600±1% | |
| Additive(kg) | 30±1% | 40±1% | 60±1% | |
| Discharging height(m) | 3.8 | 3.8 | 3.8 | |
